- TIM MX-6 (0.8 g)
- Warranty 6 Years
- Operating Ambient Temperature 0 - 40 °C
- Pump 800–2800 RPM (PWM controlled)
- Current | Voltage 0.35 A | 12 V DC
- Cold Plate Copper, Micro Skived Fins
- Tube Length 450 mm
- Tube Diameter Outer: 12.4 mm / Inner: 6.0 mm
- Weight 2005 g
| Fan dimensions | 120 x 120 x 25 mm |
| Fan speed | Main fan: 600 - 3000rpm ± 100 VRM Fan: 400 - 2500 RPM ± 100 |
| Fan airflow | 77 CFM max. |
| Noise | |
| Fan connector | 4-Pin |
| Radiator dimensions | 398 x 120 x 38 mm |
| Radiator material | Aluminum |
| Pump connector | 4-Pin PWM |
| Socket Compatibility | Intel Socket: 1700, 1851 AMD Socket: AM4, AM5 |
| LED Lighting | None |
Integrated VRM Fan
PWM-controlled fan lowers the voltage regulator temperature, ensuring stable performance.
Offset Mounting for Intel and AMD
Shifts the cold plate to the CPU hotspot for more efficient heat transfer.
Intel Contact Frame
Optimized contact pressure distribution for longer CPU lifespan and improved heat dissipation.
Integrated Cable Management
Fan cables integrated into the sleeving simplify installation and minimize cable clutter.
The New P12 Pro Fans
More Performance at Any Speed
The P12 Pro unleashes its full potential: quieter and more powerful at low speeds, with greater performance reserves under load - for maximum cooling without compromise.
- Speed: 600 - 3000 RPM
- Fluid Dynamic Bearing
- Static Pressure: 6.9 mmH2O
- Airflow: 77 cfm
Premium-Class Radiator
The 38 mm radiator not only enhances heat dissipation but also holds more liquid than conventional 27 mm radiators. This reduces heat buildup and ensures more efficient handling of temperature spikes.
Premium Tubing
Reinforced EPDM tubing with braided sheathing for increased durability.
Easy Installation
Pre-installed, pre-wired fans, straightforward mounting, and an animated online manual.
Includes MX-6 Thermal Paste
Simply apply in a cross pattern—the water pump’s cold plate distributes the paste evenly.
Two Control Options
With the splitter cable, the pump, VRM fan, and radiator fans can be controlled separately or synchronized via a single PWM signal with the all-in-one cable.
Check Your Case for Compatibility
Please note that the Liquid Freezer requires at least 63 mm of clearance for installation
Limited Compatibility with Certain Motherboards
Some motherboards may be incompatible with the Liquid Freezer III Pro due to oversized SSD coolers in the M.2_1 slot. For affected motherboards, Arctic provide a compatible M.2 cooler free of charge.
Availability:
in stock
Condition:
new
GTIN:
4895265000218
MPN:
ACFRE00178A
CPU Coolers
CPU Cooler Colour:
Black
CPU Cooler Fan Quantity:
2
CPU Cooler Fan Size:
120mm
CPU Cooler Lighting:
None
CPU Cooler Socket:
- AMD AM4 / AM5
- Intel LGA1700
CPU Cooler Style:
AIO Liquid Cooler
New features
Manufacturer:
Arctic
