Optimised for Static Pressure
During the development of the new P12, special emphasis was placed on a focused airstream and thus a high static
pressure. The fan guarantees extremely efficient cooling, even with increased air resistance.
Therefore, the P12 is particularly suitable for use on heatsinks and radiators.
High Quality Bearing
Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. As a result, there is less heat development as well as less bearing noise, which means you can enjoy a longer service life from your fan.
Virtually Silent Motor
At low fan speed, the motor is the main source of unwanted noise. A motor developed in Germany with an enhanced bearing reduces friction and noise.
Two Way Installation
- Push warm air out of the case
- Pull cool air into your case
Fan Speed: 1050 rpm
Airflow: 24.1 CFM/ 41 m³/h
Static Pressure: 0,50 (mm/H2O)
Noise Level: 0.08 Sone
Fan Frame: Standard
Controll Type: Fixed Speed
Connector: 3-Pin- Connector
Fan Bearing: Fluid Dynamic Bearing
Typical Voltage: 12 V DC
Starting Voltage: 4.8 V
Current: 0.09 A
Cable Lenght: 400 mm
Length: 120 mm
Width: 120 mm
Height: 25 mm
Weight: 139 g
Connector Type:
- 3-pin
GTIN:
4895213701365
MPN:
ACFAN00130A
Fan Flow:
Normal Direction
Case Fans
Airflow:
24cfm
Blade Colour:
Black
Fan Size:
120mm
LED Lighting:
None
New features
Manufacturer:
Arctic Cooling
