CORSAIR RM750x series fully modular power supplies are built with the highest quality components to deliver 80 PLUS Gold efficient power to your PC, with virtually silent operation.
Dimensions | W | D | H | ||
150mm | 180mm | 86mm | |||
ATX Spec | ATX v2.4 / EPS12V 2.92 | ||||
Effiency | 80Plus Gold 20% Load = 89.98% 50% Load = 91.84% 100% Load = 89.90% |
||||
Fan | 140mm Low Noise Fan with Zero RPM Mode 20% Load = 6dBA 50% Load = 12.4dBA 100% Load = 23.0dBA |
||||
Connectors | Molex | Floppy | SATA | ||
8 | 1 (adapter) | 9 | |||
PCI-E | M.board | AUX | |||
4 x 6/8 Pin | 20/24 | 2 x 4/8 Pin | |||
Output Current | +3.3v | +5v | +12v | ||
25A | 25A | 62.5A | |||
-12v | -+5vsb | 12v Rails | |||
0.8A | 3A | 1 | |||
+3.3v & 5v Power | 150W | ||||
+12v Power | 750W | ||||
-12v Power | 9.6W | ||||
+5vsb Power | 15W | ||||
Total Power | 750W | ||||
Input Voltage | 100-240v Auto | ||||
Modular | Fully Modular | ||||
Motherboard Cable Lengths | ATX 24pin = 61cm 4/8 Pin = 65cm |
CORSAIR RMx series fully modular power supplies are built with the highest quality components to deliver 80 PLUS Gold efficient power to your PC, with virtually silent operation.
High efficiency operation for lower power consumption, less noise and cooler temperatures.
A specially set fan curve ensures that, even at full load, fan noise is kept to a minimum.
At low and medium loads the cooling fan switches off entirely for near-silent operation.
Premium internal components ensure unwavering power delivery and long-term reliability.
Only connect the cables your system needs, making clean and tidy builds easier.
A 160mm-long casing ensures an easy fit in almost all modern enthusiast PC cases.
Your guarantee of reliable operation that will last across several system builds.
