- AMD Socket AM5：Supports AMD Ryzen™ 7000 Series Processors
- Unparalleled Performance：5+2+1 Phases Digital VRM Solution
- Dual Channel DDR5：2*SMD DIMMs with AMD EXPO™ & Intel® XMP Memory Module Support
- SuperSpeed Storage：PCIe 4.0 x4 M.2 Connector
- EZ-Latch：PCIe x16 Slot with Quick Release Design
- Fast Networks：Wi-Fi 6E 802.11ax & 2.5GbE LAN
- Extended Connectivity：DP, HDMI
- Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
- Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card
| Form Factor | Mini ITX Form Factor; 17.0cm x 17.0cm |
| CPU Socket | AM5 - CPU Support |
| Chipset | AMD A620 |
| Memory Slots | 2 x DDR5, supporting up to 96 GB |
| Memory Speed | DDR5 4400-6400 Non-ECC |
| PCI Slots | 0 |
| PCI-Express 16x | 1 x PCI Express x16 slot, running at x16 (PCIEX16) (The PCIEX16 slot conforms to PCI Express 4.0 standard.) |
| PCI-Express 4x | 0 |
| PCI-Express 1x | 0 |
| Multi-GPU | - |
| USB Ports | External 1 x USB 3.2 Gen1 Type C Port - CPU 1 x USB 3.2 Gen2 Type A port - CPU 1 x USB 3.2 Gen1 Type A port - Chipset 3 x USB 2.0/1.1 Type A ports - (1 x CPU, 2 x Chipset) Internal: 1 x USB 3.2 Gen1 Type C Internal - Chipset 2 x USB 3.2 Gen 1 - Chipset (1 header - Type A Front Panel Style) 2 x USB 2.0/1.1 - Chipset (1 header) |
| Audio | Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. |
| Graphics | 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz * Support for DisplayPort 1.4 version. - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. (Supported processors only ) |
| LAN | 1 x Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless | Realtek® Wi-Fi 6E RTL8852CE - WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.3 - Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate (Actual data rate may vary depending on environment and equipment.) |
| SATA Ports | 2 x SATA 6Gb/s port(s) |
| SATA Express | - |
| M.2 Socket | 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) |
| Lighting | 1 x adressable RGB header, 1 RGB LED strip header |
| Fan Headers | 1 x CPU fan header 2 x system fan header |
| PSU Connectors | 24pin + 8pin AUX |
See more info at www.gigabyte.com
Form Factor:
Mini-ITX
GTIN:
4719331855826
MPN:
A620I AX
Motherboards
Chipset:
AMD A620
M.2 Ports:
1
Memory Slots:
2
Memory Type:
DDR5
PCI:
0
PCI Express 16x :
1
PCI Express 1x:
0
SATA Ports:
2
Socket Type:
AM5
Wireless Support:
Lighting Headers:
Supports RGB and Digital RGB
Thunderbolt Add-in Card Support:
New features
Manufacturer:
Gigabyte
